Description
Continuing to set the benchmark for marine audio entertainment, FusionÕs new XS Series subwoofer features their trademark quality audio reproduction and enhanced marine aesthetics at a mid-range price point. Optimized for use in the marine environment, and built for performance, the XS subwoofer is designed to consistently produce quality low frequency audio at any volume level, season after season.
With an IP65 weatherproof rating, True-Marine accreditation and an industry-leading 3-year warranty, you can enjoy peace of mind that your XS Series subwoofer is built to last on your boat.
Features:
Versatile Design
-Designed to add low frequencies to your audio system, the XS Series subwoofer features versatility in wiring options, providing different ways to integrate one into your audio entertainment setup. This can simplify installation, reduce system cost, and is an easy way to add bass.
-Wire your subwoofer traditionally into your system through an amplifier, or alternatively create a 2.1 audio zone by connecting two speakers and a subwoofer directly to a Fusion multi-zone stereo with DSP, without the need to use an external amplifier. Simply connect a pair of speakers to the zone 1 speaker connections, and the XS Series subwoofer to the left and right speaker connections of zone 2, then select the applicable DSP profile for setup
IP65 Weatherproof
-Perfect for installation both indoors and outdoors, the XS Series subwoofer is rated IP65 for water and dust ingress protection from the front when installed correctly, while also meeting industry standards for UV and salt fog protection.
The True-Marineª Standard
-As a True-Marine product, the XS Series speakers are designed and engineered for the harsh marine environment. Once a product has been subject to rigorous environmental testing and passed our stringent True-Marine approval process, it is awarded the accreditation and recognized with an industry-leading 3-year consumer warranty
Two Grille Options Included
-The Classic style subwoofer is supplied with both Classic White and Classic Black grilles in the box, letting you choose the finish to suit your vessel without the hassle of having to purchase an extra grille.
Designed To Comply With ISO12216
-The XS Series have passed stringent pressure and water tightness tests in accordance to ISO12216 (D1.1 for Areas II, III and IV). This is critically important as it ensures the boat builders and consumers alike are installing genuinely safe speakers on board their vessel. By achieving ISO12216 compliance is a recognition of the product's superior design and build quality
Spec:
SUBWOOFER SIZE: 10"
PEAK POWER: 600 Watts
RMS POWER RATING: 120 Watts
EFFICIENCY (1W/1M): 87 dB
FREQUENCY RESPONSE: 30 Hz - 2 kHz
NOMINAL IMPEDANCE: 4 ohms
RMS: 40 - 300 W/Ch
CONE / SURROUND MATERIAL: Polypropylene with rubber surround
MOUNTING DIAMETER CLEARANCE: 223mm (8-3/4")
MOUNTING DEPTH CLEARANCE: 113mm (4-7/16")
OPTIMUM ENCLOSURE VOLUME: 40L
OPERATING TEMPERATURE RANGE: 0 to 50¡C (32 to 122¡F)
STORAGE TEMPERATURE RANGE: -20 to 70¡C (-4 to 158¡F)
