| Physical dimensions (HxWxD) |
60 x 188 x 123.5 mm |
| Weight |
556 g |
| Water rating |
IPX7 (front panel only, when properly installed) |
| Power input |
10.8-16 VDC |
| Operating temperature range |
0¡ to 50¡ C |
| Current (max) |
15 A |
| NMEA 2000 LEN |
1 (50 mA) |
| Bluetooth wireless range |
10 metres |
| ANT wireless range |
3 metres |
| Wireless frequencies/protocols |
Bluetooth 2.4 GHz @ +1.9 dBm nominal
ANT 2.4 GHz @ +1.9 dBm nominal |
| Compass-safe distance |
150 mm |
| Stereo features |
|
| Display |
128 x 64 optically bonded monochrome LCD |
| Built-in amplifier |
Class-AB |
| Peak power |
200 W |
| Rated power output (4 Ohm) |
26 W rms x 4 @ 14.4 V input < 10% THD |
| Fusion-Linkª control |
MS-RA70: Yes (smartphone and Garmin watch)
MS-RA70N: Yes (MFD, smartphone and Garmin watch) |
| Multi-Zoneª technology |
2 zones |
| Bluetooth wireless technology |
Yes |
| ANT wireless technology |
Yes |
| DAB+ ready |
MS-RA70 and MS-RA70N only; (requires DAB100A antenna module) |
| NRX remote compatibility |
MS-RA70N only |
| Multi-language interface |
Dutch / English / French / German / Italian / Spanish |
| Fits DIN-sized cutout |
Yes |
| Software updates |
USB |
| Warranty |
1 year |
| Sources |
|
| Sources |
AM / FM / Bluetooth / USB audio / iPhone / iPod / AUX x1 / AOA
MS-RA70 and MS-RA70N only: DAB+ ready (available in Europe and Australia only) |
| Connectivity |
|
| Auxiliary input |
One RCA input (AUX) |
| NMEA 2000 |
MS-RA70N : 1 port |
| USB 2.0 |
One USB 2.0 port |
| AM/FM radio |
One Motorola antenna connector port |
| Speaker |
2 x speaker connections (2 zone amplified) |
| RCA Pre-out (left, right and subwoofer) |
2 zones (requires external amplification) |
| Line out |
2 (1 x L + R per zone, requires external amplification) |
| Subwoofer out |
1 x mono output (requires external amplification) |
