| Physical dimensions (HxWxD) |
MS-RA60: 2.68" x 6.18" x 4.06" (68 x 156.9 x 103.2 mm)
MS-RA210: 2.68" x 6.18" x 4.99" (68 x 157 x 126.6 mm) |
| Weight |
MS-RA60: 11.1 oz (316 g)
MS-RA210: 12.4 oz (350 g) |
| Water rating |
IPX6 and IPX7 (front panel only, when properly installed) |
| Power input |
10.8-16 VDC |
| Operating temperature range |
32¡ to 122¡ F (0¡ to 50¡ C) |
| Current (max.) |
15 A |
| NMEA 2000¨ LEN |
MS-RA210: 1 (50 mA) |
| Bluetooth¨ wireless range |
Up to 30 ft (10 metres) |
| ANT wireless range |
Up to 10 ft (3 metres) |
| Wireless frequencies/protocols |
Bluetooth 2.4 GHz @ +12 dBm nominal
|
| Compass-safe distance |
5.9" (150 mm) |
| Display |
MS-RA60: 2.3" perimeter bonded monochrome dot matrix LCD
MS-RA210: 2.7" optically bonded colour LCD |
| Built-in amplifier |
Class-D (minimum 4 Ohm impedance) |
| Peak power |
MS-RA210: 200 W
MS-RA60: 180 W |
| Rated power output (4 Ohm) |
MS-RA60: 22 W rms x 4 @ 14.4 V input < 10% THD
MS-RA210: 26 W rms x 4 @ 14.4 V input < 10% THD |
| Built-in Digital Signal Processing |
MS-RA210: Yes (with preconfigured DSP profiles) |
| Fusion-Linkª control |
MS-RA60: Yes (with smartphone and Garmin watch)
MS-RA210: Yes (with MFD, smartphone and Garmin watch) |
| Multi-Zoneª technology |
2 zones |
| Bluetooth wireless technology |
Yes |
| ANT wireless technology |
Yes |
| SiriusXM-ready |
MS-RA210: Yes (requires SiriusXM Connect vehicle tuner) |
| DAB+ ready |
MS-RA60: Yes (DAB tuner built in)
MS-RA210: Yes (requires DAB100A antenna module) |
| NRX remote compatibility |
MS-RA210: Yes |
| Warranty |
1 year |
| Auxiliary input |
One RCA input (AUX) |
| NMEA 2000 |
MS-RA210: 1 port |
| USB 2.0 |
MS-RA210: 1 port |
| SiriusXM satellite radio |
MS-RA210: 1 port (requires SiriusXM Connect vehicle tuner, does not support traffic and weather) |
| AM/FM radio |
One Motorola antenna connector port |
| Speaker |
MS-RA60: 4 x speaker connections (2 zone amplified)
MS-RA210: 4 x speaker connections (2 zone amplified) |
| Speaker Specifications |
| Physical dimensions (HxWxD) |
EL Speaker: 6.93" x 2.32" (176 x 59 mm)
XS Classic Speaker: 6.97" x 3.19" (177 x 81 mm)
XS Sports Speaker: 6.97" x 3.27" (177 x 83 mm) |
| Peak power (Watts) |
EL Speaker: 80 W
XS Speaker: 200 W |
| RMS power (Watts) |
EL Speaker: 20 W
XS Speaker: 50 W |
