Description
The Mavic 2 Enterprise is the world's smallest and most capable drone built for commercial users. It is the ultimate expression of DJI's core aerial and imaging technologies embodied in an ultra-compact and foldable design that powers your every move.
Now comes with a FREE Enterprise Shield Cover
Product Description
FLIGHT TIME
|
DIGITAL ZOOM
|
VIDEO RESOLUTION
|
CONTROL RANGE
|
GIMBAL
|
EFFECTIVE PIXELS
|
| 31 Min |
32 x
|
4k 30fps |
10 km |
3-axis |
48mp |
Capture accurate details in any mission with the Mavic 2 Enterprise Advanced – a highly versatile yet compact tool that packs a whole lot of performance upgrades. With thermal and visual sensors, the M2EA supports 32× digital zoom and is capable of centimeter-level positioning accuracy with the RTK module.
High-resolution Thermal
Make informed decisions by quickly identifying objects onsite using the M2EA’s integrated high-resolution thermal sensor, which supports Spot Meter and Area Measurement.
Zoom in to Stay Safe
Capture clear images and videos from a safe distance. The M2EA’s high-resolution visual camera supports ultra zoom, so no detail is missed.
Dual-vision at Your Service
Tap to switch between visual, thermal, or split-view feeds for different project needs.
Accurate Positioning
Achieve centimeter-level accuracy using the M2EA with the RTK Module3. Create up to 240 waypoints to conduct automated, detailed inspection missions in complex environments.
Maximum Flexibility
The lightweight and portable M2EA can take off in less than a minute. Zip through complex operating environments thanks to the faster ascent and descent speed.
IN-BUILT CONTROLS
Fly with confidence using a range of advanced controls that are sophisticated in design and refined to give you the ultimate flying experience.
LESS INTERFERENCE, ENHANCED TRANSMISSION
A sheer flying performance with OcuSync 2.0 which supports automatic dual frequency band switching. This capability ensured a more reliable and stable flight and enhanced video transmission of up to 10 km at 1080p resolution.
MOVE WITH GRACE
Swiftly manoeuvre through complex environments with a powerful propulsion system that boasts minimal sound, and offers extended flight time of up to 31 minutes and a maximum speed of 72 kph.
MORE ROOM FOR YOUR MISSIONS
With a 24 GB internal storage, you can now store a lot more data for your missions, allowing you to get more done without the constant need of transferring images manually over SD card.
FLIGHT TIME WITH EACH ACCESSORY
Max flight time (no wind) of Mavic 2 Enterprise Advanced + M2EA Spotlight: 24 min; Spotlight turned off 28 min
Max flight time (no wind) of Mavic 2 Enterprise Advanced + M2EA Speaker: 27 min; Speaker turned off 28 min
Max flight time (no wind) of Mavic 2 Enterprise Advanced + M2EA Beacon: 29 min; Beacon turned off 30 min
Max flight time (no wind) of Mavic 2 Enterprise Advanced + M2EA RTK Module: 28 min
SELF-HEATING BATTERIES FOR ADVERSE ENVIRONMENTS
In the rugged terrains of New Zealand, you can rest assure that the Mavic 2 Enterprise will not falter. In demanding cold climates, the Mavic 2 Enterprise adapts with a suite of smart self-heating batteries that are capable of working in sub-zero temperatures.
OMNIDIRECTIONAL OBSTACLE SENSING
Fly safer than ever, experience an unrivalled flight with the Mavic 2 Enterprise's omnidirectional obstacle sensing. This advanced sensing system enables you to fly and hover with more stability than ever in a wide range of open and complex environments.
ADVANCED PILOT ASSISTANCE SYSTEM (APAS)
Sense and avoid with ease, the Advanced Pilot Assistance System (APAS) intuitively detect objects near your drone's every move, letting you easily fly around or over an obstacle, particularly in tight spaces. Instead of the craft going to a halt when an obstacle is encountered the Mavic 2 Enterprise will avoid the obstacle and continue on its original course.
DIRECT FLIGHT CONTROL
Access camera and accessory settings, intelligent flight modes and more with a single touch.
CONDUCT AUTOMATED FLIGHT
Perform repeatable data collection missions and conduct them automatically.
ULTRA-PORTABLE
Following the key feature of the Mavic series, the Mavic 2 Enterprise is slim enough to be carried anywhere and engineered to handle any tasks whenever duty calls. At 905 g the Mavic 2 Enterprise can be folded in an instant and stored at the side of any belt package. This feature enables the bearer instant power that's easily accessible and transportable.
RTK Module sold separately.
Product Specifications
AIRCRAFT
Takeoff Weight (Without Accessories): 909g
Max Takeoff Weight: 1100g
Dimensions (L×W×H):
Folded: 214×91×84mm
Unfolded: 322×242×84mm
Unfolded+Spotlight: 322×242×114mm
Unfolded+Beacon: 322×242×101mm
Unfolded+Speaker: 322×242×140mm
Unfolded+RTK Module: 322x242x125mm
Diagonal Distance: 354 mm
Max Ascent Speed:
6 m/s (S-mode)
5 m/s (P-mode)
4 m/s (S-mode with accessories)
4 m/s (P-mode with accessories)
Max Descent Speed:
Descend Vertically
5 m/s (S-mode)
4 m/s (P-mode)
Tilt
7 m/s (S-mode)
4 m/s (P-mode)
Max Speed: 72 kph (S-mode, without wind)<br>50 kph (P-mode, without wind)
Max Service Ceiling Above Sea Level: 6000 m
Max Flight Time:
31 min (measured while flying at 25 kph in windless conditions)
28 min (RTK module attached)
29 min (with beacon turned on)
30 min (with beacon turned off)
24 min (with spotlight turned on)
28 min (with spotlight turned off)
27 min (with speaker turned on)
28 min (with speaker turned off)
Max Wind Speed Resistance: 10 m/s (scale 5)
Max Tilt Angle:
35°(S-mode, with remote controller)
25°(P-mode)
Max Angular Velocity:
200°/s (S-mode)
100°/s (P-mode)
Operating Temperature: -10° to 40° C
GNSS: GPS+GLONASS
Hovering Accuracy Range:
Vertical:
± 0.1 m (with RTK)
± 0.1 m (with Vision Positioning)
± 0.5 m (with GPS Positioning)
Horizontal:
± 0.1 m (with RTK)
± 0.3 m (with Vision Positioning)
± 1.5 m (with GPS Positioning)
Operating Frequency:
2.400-2.4835 GHz;
5.725-5.850 GHz
Transmitter Power (EIRP):
2.400 - 2.4835 GHz
FCC: ≤26 dBm；
CE: ≤20 dBm；
SRRC: ≤20 dBm;
MIC: ≤20 dBm
5.725 - 5.850 GHz
FCC: ≤26 dBm;
CE: ≤14 dBm;
SRRC: ≤26 dBm
Internal Storage: 24GB
M2EA Thermal Camera
Sensor: Uncooled VOx Microbolometer
Focal Length:
Approx. 9mm
35 mm format equivalent: Approx. 38mm
Sensor Resolution: 640×512 @30Hz
Digital Zoom: 16 ×
Pixel Pitch: 12 μm
Spectral Band: 8-14 μm
Photo Format: R-JPEG
Video Format: MP4
Metering Method: Spot Meter, Area Measurement
FFC: Auto/Manual
M2EA Visual Camera
Sensor: 1/2” CMOS, Effective Pixels: 48 M
Lens:
FOV: 84°
35 mm format equivalent: 24 mm
Aperture: f/2.8
Focus: 1 m to ∞
ISO Range:
Video: 100-12800 (auto)
Photos: 100-1600 (auto)
Digital Zoom: 32×
Max Image Size: 8000×6000
Still Photography Modes:
Single shot
Interval: 2/3/5/7/10/15/20/30/60 s
Panorama: Sphere
Video Resolution:
3840×2160@30fps
1920×1080@30fps
Photo Format: JPEG
Video Format: MP4
Gimbal
Mechanical Range:
Tilt: -135°- +45°
Pan: -100°- +100°
Controllable Range:
Tilt: -90°- +30°
Pan: -75°- +75°
Stabilization: 3-axis (tilt, roll, pan)
Max control speed: 120°/s
Angular Vibration Range: ±0.005°
Sensing System
Sensing System: Omnidirectional Obstacle Sensing[1]
Forward:
Precision Measurement Range: 0.5 - 20 m
Detectable Range: 20 - 40 m
Effective Sensing Speed: ≤ 14m/s
FOV: Horizontal: 40°, Vertical: 70°
Backward:
Precision Measurement Range: 0.5 - 16 m
Detectable Range: 16 - 32 m
Effective Sensing Speed: ≤ 12m/s
FOV: Horizontal: 60°, Vertical: 77°
Upward:
Precision Measurement Range: 0.1-8 m
Downward:
Precision Measurement Range: 0.5 -11m
Detectable Range: 11-22 m
Sides:
Precision Measurement Range: 0.5 - 10 m
Effective Sensing Speed: ≤ 8m/s
FOV: Horizontal: 80°, Vertical: 65°
Operating Environment:
Forward, Backward and Sides:
Surface with clear pattern and adequate lighting
(lux > 15)
Upward: Detects diffuse reflective surfaces(>20%)
(walls, trees, people, etc.)
Downward: Surface with clear pattern and adequate lighting
(lux > 15)Detects diffuse reflective surfaces (>20%
(walls, trees, people, etc.)
Remote Controller
Operating Frequency:
2.400 - 2.483 GHz;
5.725 - 5.850 GHz
Max Transmission Distance (unobstructed, free of interference):
2.400 - 2.483 GHz; 5.725 - 5.850 GHz<br>
FCC: 10000m<br>
CE: 6000m<br>
SRRC: 6000m<br>
MIC: 6000m
Transmission Power (EIRP):
2.400-2.4835 GHz：
25.5 dBm（FCC）；18.5 dBm（CE）19 dBm（SRRC）；18.5 dBm（MIC）
5.725-5.850 GHz：
25.5 dBm（FCC）；12.5 dBm（CE）18.5 dBm（SRRC）
Storage: ROM 16GB + microSD Extensible Storage
Video Output Port: HDMI Port
Built-in Battery:
Type: 18650 Li-Po （5000 mAh @ 7.2 V）
Charging Mode: Charged with USB charger at 12V/2A
Rated Power 15 W
Charging time: 2 hr (with a USB charger at 12V/2A)
Operating Current/Voltage: 1800mA ⎓ 3.83V
Battery Life: Built-in Battery Approx. 2.5 hr
Operating Temperature: -20° C - 40° C
RC Size:
Folded without Joystick: 177.5 x 121.3 x 40 mm
Unfolded with Joystick: 177.5 x 181 x 60 mm
Weight: Approx. 630 g
Intelligent Flight Battery:
Main Link: 17.6V ⎓ 3.41A or 17.0V⎓3.53A
USB: 5.0 V ⎓ 2.0 A
RTK Module - (Purchased Separately)
Dimensions: 69 mm x 69 mm x 59mm
Connections: Micro USB Port
RTK Positioning Precision:
In RTK FIX
1cm+1ppm (Horizontal)
1.5cm+1 ppm (Vertical)
M2EA Spotlight
Dimensions: 68×60×41mm
Connections: Micro USB Port
Operating Range: 30 m
Power: Max 26W
Illuminance: FOV17°, Max: 11lux @ 30m Straight
Intelligent Flight Battery
Capacity: 3850 mAh
Voltage: 15.4V
Max Charging Voltage: 17.6V
Battery Type: LiPo
Energy: 59.29 Wh
Net Weight: 297g
Charging Temperature: 5℃ - 40℃
Operating Temperature Range: -10℃ - 40℃
Heating Methods: Manual Heating, Auto Heating
Temperature: -20℃ - 6℃
Heating duration: 500s (Max)
Heating Power: 55W (Max)
Charging Time: 90 mins
Max Charging Power: 80W
M2EA Beacon
Dimensions: 68mm×40mm×27.8mm
Connections: Micro USB Port
Power: Avg. 1.6W
Controllable Range: 5000 m
Light intensity:
Min Angle: 55 cd;
Light intensity: 157cd
APP / Live View
Video Transmission System: OcuSync 2.0
Mobile App: DJI PILOT(Android Version)
Live View Quality:
Remote Controller:
720p@30fps / 1080p@30fps
Max Live View Bitrate: 40Mbps
Latency: 120 - 130 ms
Required Operating System: ios 10.0 or later Android 5.0 or later
M2EA Speaker
Dimensions: 68×55×65 mm
Connections: Micro USB Port
Power: Max 10W
Decibel: 100 db @ 1 meter distance
Max Bitrate: 16kbps
SD Cards
Supported SD Cards:
Micro SD™
Supports a microSD with capacity of up to 128 GB.
A UHS-I Speed Grade 3 rating microSD card is required.
Footnotes
[1]Omnidirectional Obstacle Sensing includes left/right, up/down, and forward/backward obstacle sensing. Sensing for left/right directions is only available in ActiveTrack or Tripod Mode. Omnidirectional Obstacle Sensing does not fully cover the circumference of a 360-degree arc. And left and right obstacle sensing system only works in specific modes and environments. DJI warranty does not cover any loss caused by crashing when flying left or right, even when ActiveTrack or Tripod mode is activated. Please be aware of your surroundings and App notifications when operating the Mavic 2 to ensure safety.
In The Box
Aircraft x 1
Smart Controller x 1
Intelligent Flight Battery x 1
Gimbal Protector x 1
Charger x 1
Power Cable x 1
Propellers (Pair) x 2
Spare Control Stick (Pair) x 1
USB Adapter x 1
Extended Port Cover x 1
Speaker x 1
Spotlight x 1
Beacon x 1
Protector Case x 1
Manuals x 1
Enterprise Shield Basic (Mavic 2 Enterprise Advanced) NZ x 1
